FSE High Lead Ball Screw

Features

• Superior High-Speed Performance
  • Extreme Velocity: Delivers linear speeds of 100 m/min or higher, perfectly meeting the dynamic requirements of high-speed cutting and rapid automation.
  • High DN Value: Achieves a standard value of 130,000, which can be increased to 140,000 with specialized fixed-fixed end support configurations.
  • Efficiency Optimization: The high-lead design achieves rapid movement at lower motor RPMs, reducing heat generation and thermal expansion to maintain long-term machining precision.
• High Rigidity & Durability
  • Multi-Start Thread Design: Available with multi-start threads to increase the number of load-bearing steel balls, significantly enhancing structural rigidity and service life.
  • Enhanced Structural Stability: Operating at lower rotational speeds helps avoid the resonance frequencies of long screws, reducing wear on the ball circulation system.
• Advanced Low Noise & Smoothness
  • Optimized Circulation System: Specially developed return units ensure smooth ball movement at high speeds, protecting components from damage and ensuring consistent quality.
• High Efficiency & Reversibility
  • The larger lead angle reduces mechanical losses, resulting in higher energy conversion efficiency. Its excellent reversibility makes it ideal for applications requiring manual override or force feedback.

Diameter(mm): Ø16~ Ø50
Industries

• High-Speed Automation Equipment
• CNC Precision Machine Tools
• Electronics & Semiconductor Equipment
• Injection & Press Machinery
